Alignment, profile and cross-sections
Horizontal and vertical geometry to the applicable road standard, with full cross-section sets at the required chainage interval.
Consultancy & Design
Civil Engineering
Core civil design and detailing for roads, drainage, water supply, retaining structures and site development — dimensioned so the site team can build from it without a phone call.
Overview
Why this matters on your contract
A civil design is only finished when someone can build from it. Drawings that are technically correct but dimensionally incomplete generate a stream of site queries, each one a small delay and an opening for a variation claim. We treat the site engineer as the real audience for every sheet we issue.
Our civil team works across roads, drainage, water supply, earthworks and general site development, to Nepal Road Standards, departmental specifications and the relevant district rate framework. Where a design decision has a cost consequence — a steeper gradient against a longer retaining wall, a deeper invert against a pumping station — we set the options out with quantities attached so the choice is made on numbers.
What you receive
- Complete drawing set in AutoCAD and PDF, with drawing register
- Design calculations and assumptions in an auditable format
- Quantity schedules tied directly to the drawing set
- Technical specification clauses for the works designed
- Civil 3D corridor model where the project scope justifies it
Scope
What the service includes
Every element below is covered as standard. Anything outside it is quoted separately and agreed before we begin.
Drainage and hydraulic design
Catchment analysis, culvert and drain sizing, outfall design and roadside drainage detailing sized for realistic return periods.
Earthwork and mass-haul optimisation
Cut and fill balance, haul distance analysis and borrow or spoil strategy — usually the single largest cost lever on a road package.
Retaining and protection structures
Gravity, cantilever and gabion retaining walls, slope protection and river training works appropriate to hill and terai conditions.
Water supply and distribution
Pipeline sizing, reservoir capacity, pressure zoning, house connection layouts and thrust block detailing.
Site development and layout
Grading plans, access and internal roads, parking, external services routing and boundary treatment.
Our Approach
How we do this differently
01
Dimensioned for the field
Every drawing is checked for the setting-out information a site engineer actually needs. Missing dimensions are treated as errors, not omissions.
02
Quantities come with the design
Because we also quantify for a living, our drawings are produced in a way that makes measurement straightforward and unambiguous.
03
Terrain reality, not template design
Hill alignment and terai alignment are not the same problem. Our detailing reflects where the project actually is.
Questions
Common questions
If yours is not answered here, call us — the conversation is free and usually short.
+977 1 4538 720Yes. Road geometry, pavement composition, drainage and structures are designed to Nepal Road Standards and the relevant DoR specifications, and we routinely prepare packages that are reviewed and approved by departmental engineers.
Yes, and we begin by auditing what exists so you know precisely what is usable. We will tell you if starting again is faster and cheaper than repairing an incomplete set — sometimes it is.
Always, unless you ask us not to. Take-off sheets are handed over with the drawing set so the quantity can be traced to the exact sheet and dimension it came from.
